DIAMOND AUDIO NEO 6" x 9" Motorsport High Output Neo Midrange

Features:

• 350 W RMS/700W MAX Power Handling
• Sensitivity: 96dB 1W/M
• Frequency Response: 90Hz - 10kHz
• Nominal Impedance: 4 ohm
• Mounting Depth: 3.09” (78.5 mm)
• Cut-out Diameter: 8.6” x 5.7” (218 mm x 146 mm)
• Over-All Diameter: 9.2” x 6.4” (233.5 mm x 162 mm)
• Over-All Height: 3.43” (87.2 mm)
• Heavy Duty Industrial Cast Aluminum Basket
• Waterproof Black DUPONT™ Kevlar Cone
• Neodymium Magnet Motor Structure
• US manufactured 2” Black High Temperature Coated Voice Coil



Speaker Size	6“x9”
Nominal Diameter (inch/mm)	9.193"X6.378" (233.5mmX162mm)
Description	6”x 9” Neodymium MidRange Speaker
Nominal Impedance (ohms)	4Ω
RMS Power Rating	350W
Max Power Rating	700W
Frequency Response	90Hz-10kHz
Voice Coil Diameter (inch/mm)	2"
Power Handling (RMS/Peak)	350W/700W
SPL (db)	96 dB
Re (Ω)[series]	3.2
Qms	9.971
Qes	0.558
Qts	0.528
Fs-Free Air Resonance (Hz)	90
Vas (Liter)	10.7
Cms (mm/N)	0.177
Mms (g)	17.5
Sd (cm²)	0.0207
BL (T*M)	7.785
Xmax - Inch(mm)	1.2mm
Pwr (W) NOM/MAX	350/700
Total Diameter	9.193"X6.378'' (233.5mmX162mm)
Mounting Diameter (inch/mm)	8.583"X5.748'' (218mmX146mm)
Mounting Depth	3.091'' (78.5mm)
Total Depth	3.433'' (87.2mm)
Grille	NO
Dimension - Length x Width x Height - Inches(mm)	9.193"X6.378" (233.5mmX162mm)
